Active Subwoofer System
· The Active Powered Subwoofer line brings Wet Sounds™ performance technology to the marine environment, in a complete all‐in‐one package.
This complete solution is designed with a 500 watt Class‐D high efficiency amplifier in a reinforced fiberglass sealed enclosure.
The Active 10 will bring the bass thumping power on the boat with minimal current draw to keep the party rocking on the water.
Output Power @ 14.4V 1 – 500 Watts
Frequency Response (-3dB)20Hz-150Hz
S/N Ratio (A-weight) >95dB
THD with 22k filter <0.2%
Low Input Level 100mV-4V
Hi Input Level 8V
Battery Voltage Range 10.5VDC-16VDC
Crossover Type LP
Variable Low Pass Range 35Hz-150Hz
Crossover Slope 12dB/Oct
Bass Boost ( 45Hz) 0-12dB
Subsonic Filter 24dB @ 20Hz
Variable Phase 0 / 180
Remote Bass Control Yes
Remote Auto Start Yes
Protection Circuit Thermal, Over & Under Voltage
Amplifier Fuse & Holder 1 x 25A
Size L x W x H (IN) 11.5″ x 14.5″ x 12.75″
Net Weight 13.6kg / 30 lbs
