HIGH-END HYBRID VALVE RECEIVER WITH POWERFUL OUTPUT STAGE AND BLUETOOTH® APTX™

High-end hybrid receiver with tube preamplifier and a high-performance transistor output stage

High-quality DAB+/FM tuner

Analogue inputs incl. high-quality MM-phono input

Digital input section with 2 optical and 2 coaxial inputs and 1 USB audio input

Bluetooth® input (4.0) with the high-end audio standard Qualcomm® aptX™

Sturdy full-metal enclosure with solid aluminium front plate and controls

The Magnat MR 780 combines elegantly audiophile hi-fi sound with substantial power reserves: Used in the pre-amp stage are high-quality selected and extensively burnt-in ECC 81 valves, ensuring that well-loved, warm sound. The output stage relies on a low-emission toroidal transformer and provides an impressive 100 watts of RMS power per channel at 4 ohms. Added to this is a virtually overwhelming range of connection options for analogue and digital sources, including Bluetooth aptX. Where necessary, a high-quality Wolfson D/A converter takes care of the signal transformation with up to 192 kHz and 24 bits. A phono pre-amplifier for MM systems, an integrated DAB/DAB+ tuner as well as an FM receiver and a large number of further details make the MR 780 one of the best stereo receivers in this price category. This high standard is clear from the very first glimpse. You can see immediately from the full-metal enclosure with its solid, brushed aluminium front panel that this unit belongs in the high-end range.

SENSITIVITY DAB/DAB+ - -100 dBm

POWER CONSUMPTION - Standby < 0,5 W Max 300 W

PEAK - 1 kHz, 4 Ohm 2 x 180 W

FREQUENCY RESPONSE - CD/Tuner/Aux/Line/Tape: 6 Hz – 90 kHz (-3,0 dB) 20 Hz – 20 kHz (+/-0,3 dB) Phono: 20 Hz – 20 kHz (+/-0,8 dB) Subsonic Filter : 16 Hz, 18 dB/Oct.

OUTPUT POWER / NOMINAL - 20 Hz – 20 kHz, THD < 1.0%, 4 Ohm, 2 x 100 W 20 Hz – 20 kHz, THD < 1.0%, 8 Ohm, 2 x 75 W

FREQUENCY RANGE FM - 87.5 – 108 MHz

FREQUENCY RANGE DAB/DAB+ - 174.928 – 239.2 MHz (Band III)

SENSITIVITY FM - -108 dBm

INPUT SENSIVITY - CD/Tuner/Aux/Line/Tape: 470 mV/100 kΩ Phono MM: 5 mV/47 kΩ

DIGITAL INPUTS - USB 2.0, type B connector Supported sampling frequencies: 44.1/48/88.2/96/176.4/192kHz Supported bit depth: 16/24bits 1. optical (Toslink™) 2. coaxial (cinch)

BLUETOOTH® INPUT - Bluetooth® 4.0 / Qualcomm® aptX™

S/N RATIO - CD/Tuner/Aux/Line/Tape: 104 dB (A) Phono MM: 82 dB (A)

COLOR - Black

DIMENSIONS (WXHXD) - 433 x 132 x 317 mm (360 mm incl. controls and connectors) Remote control: 45 x 175 x 20 mm

WEIGHT - 8.9 kg

HIGHLIGHTS- System remote control for all functions Readable, two-line clear text display with adjustable brightness (3 stages)

AMPLIFIER AND POWER SUPPLY

Separate standby power supply for low power consumption in standby mode

High-performance power supply with separately stabilised

supply voltages for the different tubes and circuits

Discrete high-performance amplifier

Output power: 100 watts of sine power per channel (4 ohms)

High-capacity filter/electrolytic capacitors

Shielded toroidal transformer

PREAMPLIFIER

MM-phono preamplifier with low-noise operational amplifiers and subsonic filters

Low-noise tube preamplifier with 2 x ECC 81 tubes

Preselected and burned-in tubes

Additional 3.5 mm audio input on the front panel for connecting portable devices

Digital inputs (2 x optical and 2 x coaxial) for sampling frequencies up to 192kHz/24bits

USB Audio 2.0 input supports sampling frequencies up to 192kHz/24bits

Bluetooth® input (4.0) supports the high-end audio standard Qualcomm® aptX™

Wolfson digital-to-analogue converter

CONNECTIONS - Headphone output with high quality 6.3 mm jack, Record Out fixed level output

CABINET - Solid aluminium control elements, Sturdy full-metal enclosure with solid, brushed aluminium front, Stable feet with damping rubber insert
