Mobile Fidelity

STUDIOTRACKER
MoFi cartridges are designed by looking back at where a record starts: On a lacquer cutting lathe like the model used at Mobile Fidelity Sound Lab. Studio Tracker features a V-Twin dual-magnet generator that mirrors the layout of the cutting head that originally made a record’s grooves.

V-TWIN DUAL-MAGNET GENERATOR
Employing two low-mass, powerful magnets aligned in a V formation parallel with the stereo record grooves, Studio Tracker accurately extracts precious details from your LPs.

ELLIPTICAL DIAMOND STYLUS
With a polymer body and elliptical stylus, Studio Tracker offers surprising bang-for-your-buck value and a rich sound distinguished with a smooth, slightly forgiving top end.

SPECIFICATIONS
-Type-Dual Magnet (MM) Stereo
-Stylus-Elliptical
-Output Voltage-3.5Mv
-Frequency Response-20–20,000Hz
-Weight-6.4g
-Tracking Force-1.8–2.2g
-Impedance-47kOhm
-Capacitance-100pF
-Compliance-Static compliance :  35 x 10e-6/dyne
-Dynamic compliance :  8 x 10e-6/dyne

FEATURES
• V-Twin dual-magnet generator
• Elliptical stylus
• Polymer body
• 3.5mV output
