Mobile Fidelity

ULTRAPHONO
Ultra-Phono replicates the wide bandwidth transparency Mobile Fidelity Sound Lab mastering engineers’ demand. Tim De Paravicini, the designer responsible for the Mobile Fidelity Gain2™ Ultra Analog cutting system, assisted with the internal circuitry to ensure your analogy system at home faithfully reproduces the music buried in the grooves of your LPs. Ultra-Phono also includes an audiophile-quality Class A headphone amplifier for intimate listening enjoyment.

CLASS-A HEADPHONE AMPLIFIER
Ultra-Phono includes a powerful Class A headphone amplifier perfect for quiet nights when you want to keep the records spinning in private. And with a 31-step volume control built into the unit, all you need to do is directly plug-in your headphones and turn it up! It's the easiest way to achieve high-fidelity vinyl playback without speakers and electronics.

ADJUSTABLE GAIN AND LOADING
With selectable gain and loading, you will be able to tailor Ultra Phono to match nearly any moving-magnet or moving-coil cartridge on the market. A readily accessible bank of toggle switches can be found on the unit’s underside to quickly adjust without the need for any tools.

HEADPHONE AMPLIFIER
-Headphone Output- 8V RMS Max, 62 Ohms, 1.5 w/ch
-Volume Control 31 steps, 2dB per/step, 62dB range
-Mute Switch-90dB
-Minimum Impedance > 10 Ohms

SPECIFICATIONS
Gain-Adjustable from 40dB - 66dB
THD < .006% (MM) / < .055% (MC)
Load Impedance (MM) -47,000 Ohms
Load Impedance (MC) 75, 100, 500, 1k, 10k, 47k Ohms
Input Capacitance- 100pF

FEATURES
• Selectable gain for MM or MC 40dB, 46dB, 60dB, 66dB
• Adjustable loading 75Ω - 47kΩ
• Class A Headphone Amplifier
• Switchable Mono mode
• Subsonic filter
• External power supply gs
