DLS Performance M369

Overview

Performance series M369 is a  6 x 9 ” 3-way triaxial with 2” mid driver and a 25 mm silk dome tweeter.

The bass driver has a cone of woven glass fibre and rubber edge. Together with a powerful magnet system, it guarantees good bass control. Grilles are included.

Small filter boxes with a 12 dB slope crossover to the tweeter and 6 dB to bass and midrange.

Specifications

• Woofer size 6" x 9" (165 x 236 mm
• Tweeter 25 mm (1") tweeter, 45 mm (2") midrange
• Power handling capacity 80 W RMS / 120 W max / 200 W peak power
• Impedance 4 ohm
• Frequency range 50 - 20.000 Hz
• Sensitivity 89,3 dB (1W/1m)
• Crossover External filter with 12 and 6 dB slope
• Outer diameter of woofer 165 x 236 mm
• Magnet size 100 mm (3,94")
• Cone material Woven glass fibre with rubber surround
• Mounting depth 86 mm ( 3,38")
• Mounting hole 155 x 221 mm (6,1 x 8,7")
• Size of filter box External cable filter
