MAGNAT Interior ICQ 82

Purchase this product

RRP: $499.95
Our Price: $499.95

Or 4 payments of $124.99
Info
Enquire about this product Print Product Information

8" 2-WAY HIGH-END RECESSED SPEAKER


Powerful and detailed reproduction for use in larger rooms

High-quality crossover with triple level adjustment for the treble and mid-ranges

High-end 25 mm fabric tweeter for maximum impulse fidelity

Swivel tweeter up to 35° for precise locatability

200 mm woofer with torsion-resistant ceramic-aluminium membrane

This particularly high-quality recessed ceiling speaker follows in all essential parameters of the Magnat Quantum technology. Like traditional home-audio boxes, the ICQ 82 is equipped with woofer and mid-tone diaphragms made with highly stable and rigid anodized ceramic-aluminum cones. This material provides extremely accurate reproduction and reveals even the finest acoustic details.  All high frequencies are reproduced with the highest pulse fidelity and freedom from distortion by a coated fabric dome tweeter. The elaborate crossover also ensures precision allocation between the high and low frequencies

PRINCIPLE - 2-way in-wall/in-ceiling loudspeaker

EQUIPMENT - 25 mm tweeter 200 mm woofer

POWER HANDLING (RMS/MAX.) - 120 / 200 watts

SENSITIVITY (2.8V/1M) - 91 dB

IMPEDANCE - 4 Ohms

FREQUENCY RESPONSE - 32 – 26000 Hz

CROSSOVER FREQUENCIES - 3800 Hz

RECOMMENDED AMPLIFIER OUTPUT - 20 - 250 Watts

OUTER DIMENSIONS Ø - 272 mm

CUTTING OUT Ø - 240 mm

MOUNTING DEPTH - 115 mm

WEIGHT - 1.7 kg

HIGHLIGHTS - High-End in-wall/in-ceiling loudspeaker. Special clamping mechanism for easy installation. Moisture-proof speaker system, suitable for use in humid rooms (bathroom)

CROSSOVER - Crossover with high-quality components and 3 settings for tweeterand midrange level

CONNECTIONS - Gold-plated push terminal

LOUDSPEAKER DRIVERS - Coated silk soft dome tweeter. Tweeter with Swivel technology (can be turned by 35°). Low-resonance aluminium woofer cone with hairline finish. Long-throw rubber surround for maximum excursion. Exclusive aluminium design protection grille
